The RocketU 1244C is the industry's fastest USB Host Controller. Each of the four USB Type-C ports is fully independent, and powered by a dedicated 10Gb/s USB 3.2 controller chip, backed by a robust PCIe 3.0 x8 host interface. This unique host controller architecture ensures each hosted USB device can operate at peak performance without saturating the bus or taxing system resources.


  • 4x Dedicated USB-Type C 3.2 10Gb/s Ports

  • Dedicated PCIe 3.0 x8 Host Interface

  • Ideal for professional-grade, High-Speed Data Acquisition & Transfer Applications

  • 4 USB-Type C ports support any industry-standard USB device or peripheral

  • Driverless Installation: Native xHCI Support

Product Information

  • B

Dedicated Per-Port Performance Architecture

4x 10Gb/s Transfer Bandwidth


Unlike most USB controllers in today’s marketplace, the RocketU 1244C supports four independent USB Type-C ports, each of which is powered by a dedicated USB 3.2 10Gb/s controller. This unique Per-Port Performance architecture enables each RocketU 1244C to deliver up to 4000MB/s of transfer bandwidth.


Blazing Fast PCIe 3.0 x8 Host Interface


The blazing fast PCIe 3.0 x8 host interface works in tandem with our Per-Port Performance architecture to ensure each individual USB port can deliver 10Gb/s of transfer bandwidth at all times, even in cases where each port is occupied and under heavy load.


Dedicated USB Controllers Provide Independent Device Paths & Power Delivery


The RocketU 1244C’s four dedicated USB 3.2 controllers enable each port to work independently and deliver up to 7.5W of power for device operation or charging purposes. The innovative PCB layout provides a dedicated USB connection pathway for each port; hosted USB devices can operate at peak performance, without the risk of interference by neighboring USB connections.

Ideal for High-Speed Data Acquisition & Capture Applications

The RocketU 1244C's performance-focused HBA architecture was designed for workflows that demand ease of integration, hot-plug capability, and rapid file transfer. The four independent 10Gb/s USB ports and PCIe 3.0 x8 host interface can easily accommodate a wide range of high-speed data acquisition applications, including imaging and capture solutions, security systems, and media archiving.

USB Cameras & Imaging/Capture Devices


Media Processing & Archiving


HighPoint RocketU 1244C 4x 10Gb/s PCIe 3.0 x8 USB Host Controller

Universal Device Compatibility    Works with any industry-standard USB 3.x/2.0/1.x device

Universal Device Compatibility


Works with any industry-standard USB 2.0/3.2 Gen1/3.2 Gen2 device

4x 10G USB-C Ports    The RocketU 1344D's four USB Type-C ports can deliver up to 1000MB/s of trasnfer bandwidth

Dedicated USB 10G Connectivity


The RocketU 1244C features four dedicated 10Gb/s USB ports

USB Device Charging    RocketU 1344D can be used to charge USB compliant devices

USB Device Charging


RocketU 1244C can be used to charge USB compliant devices

xHCI CompliantDriverless Installation: The RocketU 1344D is natively supported modern operating systems

xHCI CompliantDriverless Installation: The RocketU 1244C is natively supported modern operating systems

Ultra-High Performance:  ​  Dedicated PCIe 3.0 x4 Bus-Bandwidth

Ultra-High Performance:


Dedicated PCIe 3.0 x8 Bus-Bandwidth

The RocketU 1344D is Thunderbolt™ compliant, and can be installed into PCIe expansion chassis, such as the RocketStor 6661A

Learn More

Feature Specifications

Host Bus Interface
8-lane, 8 GT/s PCI Express 3.0 Compliant
Interface Technology
Supports up to USB 3.2 10Gb/s link speed Backwards compatible with USB 3.2 Gen2, USB3.2 Gen1 & USB 2.0
Supported Standard
UASP, xHCI
Apple M1 Platform Suport
Yes
Operating System Support (Mac compatibility)
• Compatible with PCIe slots • Mac Pro 5,1 or 7,1 • macOS 10.12.6 and later • Supports Intel & M1 chipset
Operating System Support (Windows compatibility)
• Compatible with PCIe slots • Windows 11,10,8.1 • Windows Server 2022, 2016, 2012, 2008 (64-bit editions)
Operating System Support (Linux compatibility)
• Compatible with PCIe slots • Linux kernel 3.10.0 and later
Operating System Support (VMware ESXi compatibility)
Yes

Secure Boot(PC platforms)

Windows: Support Secure Boot Disable and Enable Linux: Support Secure Boot Disable and Enable

Number of Channel / Port

4
Port Type
USB Vertical Type-C
Data Transfer Rates
10Gb/s per port
Number of Devices
4 x USB 1.x, 2.0, and 3.x compatible devices
USB port Ampage
1.5A output per port
Bus Powered Peripherals
Up to 7.5W per port for device operation or charging
External Power Support
Yes (6pin PCIe Power Connector)
USB Port Sharing
Dedicated (Not Shared): Each USB Port has a dedicated controller (ASM3142)
Form Factor
Low-Profile
Cooling system
Anodized Aluminum heat sink
Dimensions
4.57" W x 2.71" H x 0.45" D
Weight
0.46lbs
Warranty
1 Year
Compliance Certification
CE, FCC, RoHS, REACH, WEEE

Operating Environment

Work Temp:
5°C ~ 45°C
Storage Temp:
40°C ~ 65°C
Operating Voltage
PCI-e: 12V, 3.3V
Power
Typical: 8.38W (card only)
MTBF (Mean Time Before Failure)
920,585 Hours

Kit Contents

Model
RocketU 1244C
Controller card
1x Controller card
Quick Installation Guide
1x Quick Installation Guide
Low Profile Bracket
1x Low Profile Bracket
QIG
Download
Datasheet
Download

Universal Compatibility

RocketU 1244C controllers can be installed into any computing platform with an industry-standard PCIe 3.0 or 4.0 x4,x8 or 16 slot. The four independent USB Type-C ports support any industry-standard USB 2.0/ USB 3.2 Gen1/ USB 3.2 Gen2 device, including USB drives, cameras, printers, capture devices and peripherals.


Mac Pro 2019


Mac Pro 5.1 (Legacy)


Apple M1


Motherboards


PC Platforms


Workstations


Rackmounts
